Products Description
Seamless carbon steel oil well casing pipe is the core OCTG product for oil and gas well construction. It is run into boreholes to support well wall, prevent collapse, isolate different formations, avoid channeling of oil, gas and water, and guarantee safe drilling and production of oil & gas wells. Without welding seam, it owns better pressure resistance and structural integrity than welded casing pipe, widely trusted by oilfield operators, drilling contractors and petroleum engineering companies worldwide.
Product Basic Introduction
Outer Diameter: 2-3/8" ~ 20" (custom OD available).
Wall Thickness: 0.133" ~ 0.500" or customized.
Nominal Weight: Range from light weight to heavy weight casing as per API 5CT table.
Length Range: R1, R2, R3 (custom fixed length acceptable).
Steel Grades: H40, J55, K55, N80, L80, C95, T95, P110, Q125.
Thread Connection Type: STC, LTC, BTC, NU, EU, premium connection.
End Finish: Plain end, threaded & coupled (T&C).
Tolerance: Strict API 5CT dimensional tolerance on OD, WT, length and thread dimension.
Material & Executive Standard
Main standard: API Spec 5CT (latest edition).
Material: Carbon steel / low alloy carbon steel for OCTG service We provide both PSL 1 and PSL 2 level casing pipe. PSL2 requires stricter chemical control, additional non-destructive inspection and traceability, for critical deep well, high pressure and offshore projects.
Chemical Composition
Carbon (C), Silicon (Si), Manganese (Mn), Phosphorus (P ≤0.030 max), Sulfur (S ≤0.030 max), trace alloy elements for high grade.
We provide official mill test certificate (MTC) with full spectrometer / PMI chemical report for each batch.
Mechanical Properties
|
Grade |
Minimum Tensile Strength (MPa) |
Yield Strength Range (MPa) |
|
J55 |
≥517 |
379 – 552 |
|
K55 |
≥655 |
379 – 552 |
|
N80 |
≥689 |
552 – 758 |
|
L80 |
≥689 |
552 – 655 |
|
P110 |
≥758 |
758 – 965 |
Test items: Tensile test, full size collapse test, burst pressure test, Charpy impact test, hardness test. All mechanical data follow API 5CT requirements.
Production Flow
Raw steel billet incoming inspection & PMI chemical check
Heating & rotary piercing → seamless hollow tube blank
Hot rolling / elongating to reach target OD and wall thickness
Sizing & straightening
Heat treatment (Normalizing, Quenched & Tempered for high grades like N80, L80, P110)
Cutting to required length
Thread machining & coupling make-up
Non-destructive testing (UT, MT, ET)
Hydrostatic pressure test
Final dimension, thread visual inspection
Anti-rust coating, thread protector installation, marking
Bundling, packing, loading & delivery
Applications
Onshore oil well & gas well drilling and completion
Offshore oil & gas production casing string
Water injection wells, geothermal wells
Shale oil / shale gas horizontal well projects
Wellbore reinforcement, formation isolation
Petroleum engineering, oilfield service company, EPC contractor projects
FAQ
Q: Q1: What standard do your oil well casing pipes follow?
A: A: Mainly API Spec 5CT PSL1 / PSL2, the global standard for OCTG casing and tubing.
Q: Q2: What grades of seamless casing can you supply?
A: A: J55, K55, N80, L80, C95, T95, P110, Q125 and other grades. We recommend J55/K55 for shallow wells, N80/L80 for medium wells, P110 for deep high-pressure wells.
Q: Q3: Can you make custom thread and custom length?
A: A: Yes. STC, LTC, BTC, NU, EU and premium connections are available; R1/R2/R3 or fixed cut length is supported.
Q: Q4: What test documents can you provide?
A: A: Official Mill Test Certificate (MTC), PMI report, hydro test report, NDT report, heat treatment record. Third-party inspection certificate is acceptable.
Q: Q5: What trade terms do you support?
A: A: FOB, CFR, CIF, DAP, DDP, we can quote as your requirement.
Q: Q6: Is thread protector included?
A: A: Yes, plastic or metal thread protectors are equipped for all threaded casing to protect threads during shipment.
Q: Q7: What is your MOQ?
A: A: Small trial order is acceptable; bulk order for oilfield large project is welcomed.
