Products Description
SGCC DX51D Hot Dip Galvanized Steel Coil (GI Coil) is a premium cold-rolled base steel product processed through advanced hot-dip galvanizing technology. Combining the excellent ductility of DX51D steel grade and the strict quality standard of SGCC specification, this steel coil features uniform zinc coating, outstanding corrosion resistance, smooth surface finish and superior formability. It is the most versatile and cost-effective galvanized steel material widely adopted in construction, home appliance, automotive and general manufacturing industries. Manufactured in full compliance with international industrial standards, our DX51D SGCC galvanized steel coils deliver stable mechanical performance and long service life for diverse commercial and industrial applications.
|
Item |
Technical Parameters |
|---|---|
|
Product Name |
SGCC DX51D Hot Dip Galvanized Steel Coil |
|
Steel Grade |
SGCC, DX51D (equivalent to commercial quality galvanized steel) |
|
Executive Standards |
JIS G3302, EN 10142, ASTM A653, GB/T 2518 |
|
Base Material |
High-quality cold rolled carbon steel (Q195/Q235 optional) |
|
Thickness Range |
0.12mm – 3.5mm (custom precision tolerance ±1%) |
|
Width Range |
600mm – 1250mm (common sizes: 914mm, 1000mm, 1200mm, 1219mm) |
|
Zinc Coating Weight |
Z40 – Z275 g/㎡ (Z80/Z100/Z180/Z275 regular stock) |
|
Surface Spangle |
Regular spangle, zero spangle, mini spangle, big spangle (customizable) |
|
Surface Treatment |
Chromated passivated, non-chromated, oiled, dry |
|
Coil Weight |
2–8 tons per coil (custom coil weight available) |
|
Inner Diameter |
508mm / 610mm |
- Tensile Strength: 270–500 MPa, stable structural strength for general load-bearing scenarios
- Yield Strength: ≤ 380 MPa, excellent flexibility for deep processing
- Elongation: ≥ 22%, superior ductility and formability
- Adhesion Performance: Strict zinc coating adhesion test, no peeling after bending 180°
- Weather Resistance: Uniform zinc layer provides effective barrier protection, anti-rust and anti-corrosion for indoor and outdoor use
Standard Packaging: Waterproof paper, plastic film, steel strap and iron pallet packing, fully sealed to prevent moisture, rust and damage during transportation
Shipping Port: Main ports in China (Qingdao, Shanghai, Tianjin, Ningbo)
Supply Capacity: Sufficient stock of conventional specifications, support bulk order production and fast delivery
MOQ: 1 ton for trial order, 5 tons for bulk order
Applications
- Construction Industry: Roofing sheets, wall panels, corrugated sheets, steel structure accessories, guardrails, ventilation pipes, building decoration materials
- Home Appliance Industry: Shells of refrigerators, washing machines, air conditioners, water heaters, and other household electrical appliances
- Automotive Industry: Automotive interior parts, body accessories, chassis protective parts, lightweight structural components
- General Manufacturing: Hardware accessories, metal containers, pipe fittings, warehouse shelves, tooling plates
- Other Fields: Agricultural equipment, logistics facilities, outdoor engineering anti-corrosion components
FAQ
Q1: What is the difference between SGCC and DX51D galvanized steel coil? A1: SGCC is a JIS standard commercial-grade galvanized steel with no fixed mechanical value requirement, while DX51D is a European EN standard grade with clear standardized mechanical properties and stricter process control. Our SGCC DX51D combines the advantages of both standards, featuring stable quality, good formability and wider compatibility for global market demands.
Q2: What zinc coating weights are available for stock? A2: We have regular stock of Z80, Z100, Z180 and Z275 galvanized layers. Custom zinc coating from Z40 to Z275 g/㎡ is acceptable according to customer's usage and anti-corrosion requirements.
Q3: Can you provide customized size and surface treatment? A3: Yes. We support custom thickness, width, coil weight and inner diameter. Multiple surface treatments including oiled, dry, passivated and non-passivated are optional to meet stamping, painting and outdoor usage needs.
Q4: Is the galvanized layer easy to peel or crack during processing? A4: No. Our SGCC DX51D GI coils have excellent zinc layer adhesion. It can withstand 180° bending without peeling or cracking, and is fully suitable for stamping, rolling, welding and other secondary processing.
Q5: What certificates and test reports can you provide? A5: We can provide official Material Test Report (MTR), factory inspection certificate, and support SGS, BV and other third-party authority inspections to meet import customs clearance and customer quality audit requirements.
Q6: What is your MOQ and delivery time? A6: The MOQ is 1 ton for trial orders and 5 tons for bulk orders. Conventional specifications have sufficient stock and can be delivered within 3-7 days; customized products take 7-15 working days according to production schedule.
Q7: What industries is DX51D SGCC galvanized steel coil mainly used for? A7: It is widely used for building roofing and wall panels, home appliance shells, automotive accessories, hardware products, storage shelves, ventilation pipes and various anti-corrosion metal parts, covering most civil and industrial manufacturing fields.
Q8: How to ensure no rust during long-distance transportation? A8: We adopt multi-layer professional packaging with waterproof paper, moisture-proof plastic film and reinforced steel strapping. The sealed packaging effectively isolates moisture and oxidation, ensuring intact product surface during ocean and land transportation.
